Even in 1- and 2-layer circuit boards, the demand for precision and innovation can be very high. VARIOPRINT offers a wide range of technologies in this product field.
Fine line structures down to 50 µm, controlled depth-drilling or routing, complex mechanical contour cutting, manufactured using routing or laser technology in a wide range of materials. The range is enormous. Challenge us with your most demanding requirements! Highly trained specialists, including engineers, poly-mechanics and galvano-technicians look forward to your challenge.
| Design and technology |
Single and double-sided PCBs with/without through-plating in a diverse choice of materials.
| Dimension and formats |
Thickness 0.2 mm to 4.8 mm
Format up to 569x490 mm
Solder resists and additional prints
Additional prints, such as legend print, peelable mask and carbon print
Conductive pattern structuring
Conductor widths and spacings down to 50 µm / 50 µm
Complex contour machining and demanding depth milling can be executed with maximum precision and high efficiency.
| Materials |
FR4, TG 135°C with filler
FR4 highTG 170°C
Special surface requirements, such as partial hard gold on ENIG is just one example of our large portfolio.
Electroplating and copper plating
